01. Creo 3 0 Basic Part modelling Extrude, Revolve, Sweep, Helical Sweep, Swept blend, Datum Plane

2K views · Jan 6, 2022
Visit Channel: extrudesign.com
Introduction tutorial for Creo 3.0 Beginners
In this video we have discussed shape-based features Extrude, Revolve, Sweep, Helical sweep, Swept blend, Model tree items, Datum planes,  Model tree insert here feature.

With Helical sweep, we have discussed the multiple pitch options.
With the model tree, we have discussed how to use Insert feature to be more productive.
With the Swept blend, we have discussed how to create the Normal datum planes at the Trajectory curve ends.

Previous Video: https://www.youtube.com/watch?v=SkqqEilkIfQ
Next Video: https://youtu.be/AfdNzZhgUow

Also, check PTC Creo Complete Tutorial Guide for Beginners:
https://extrudesign.com/creo-tutorial-guide-beginners/
This guide list all the important topics that every mechanical engineer/drafter need to know.
